Molybdenum
Molybdenum Tube, Molybdenum Lanthanum Tube, Molybdenum pipe for thermocouple protection, Molybdenum tubes for high temperature furnaces
-
- Our Molybdenum Tube is meticulously crafted to deliver superior performance and reliability. With its excellent thermal conductivity and corrosion resistance, it is well-suited for use in industries such as aerospace, electronics, and manufacturing. Whether you require precise thermal management or reliable structural support, this tube is engineered to exceed your expectations.
-
- The seamless construction of the Molybdenum Tube ensures uniformity and consistency, making it suitable for critical operations where precision is paramount. Its high melting point and exceptional mechanical properties make it an indispensable component in demanding applications, providing long-lasting performance under extreme conditions.
|
Grade |
Mo1 |
|
Purity |
99.95（%） |
|
Impurity element |
0.05（%） |
|
Density |
≥18.3g/cm³ |
|
Appearance |
Silver gray metal luster |
|
Grade |
GB/T 4187-1984; ASTM F288-90 |
Supply state： Sintering or drilling state
Size range: ODΦ(1.0~50)mm×wall thickness(0.1~5)mm×(50~1000)mm
Special specification can be made based on customer’s requirements
Production process:
Sintered molybdenum tube: Isostatic pressure - intermediate frequency sintering - machining - finished sintered molybdenum tube.
Drilling molybdenum pipe: Finished molybdenum rod - drilling - wire cutting(
If the wall thickness is ≥0.1mm, which require wire cutting.
Application: Tungsten pipe is mainly used in thermocouple protection pipe in high temperature furnace, sapphire single crystal furnace, supporting parts in high temperature sintering furnace, etc.
Advantages: High dimensional accuracy, highly polished inner and outer surface, good straightness, no deformation under high temperature strength.
